FUNAI TD6D-M101 - Mechanical Parts List

20130327 1-21-1 E3TFGCA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Ref. No. Description Part No.
A1X FRONT ASSEMBLY E3TF4ED 1VM127499
A2 MAIN CHASSIS E4340UD 1VM120193V
A3 TOP COVER E3TG0FD 1VM328481
A4 REAR PANEL E3TFGEH 2VMS00043
A5 FAN HOLDER ASSEMBLY E43A0JD 1VM425152
A7 FOOT E6500UD 0VM416122
A9 BARCODE LABEL(UNFIGURE) E3TF4ED ----------
A10! RATING LABEL E3TFGEH ----------
A16 POWER HOLDER E3TK3FD 1VM330398
A22 TOPPER POP E3TFEED ----------
A25 VOID LABEL E3B40ED ----------
1B1 DECK ASSEMBLY CZD014/VM25E0 N25E1FL
1B3 HARD DISK DRIVE 500GB HCC545050A7E380 UHD5000HT004
B1 HDD BRACKET E3TKABD 1VM341297
B2 MODE LENS HOLDER E3TG0FD 1VM430599
B6 MECHA EARTH PLATE F E9A80UD 1VM424039B
B8 DECK PEDESTAL E9TK0FD 1VM330600
B11 FRONT BRACKET E9400UD 0VM204534D
B12 FRONT BRACKET R E9A80UD 1VM322182C
B13 BRACKET R E9600UD 1VM421062F
B14 TAPE HIMELON H9206JD 0VM413956
B15 TOP COVER CUSTION E9S24JD 1VM444539
B18 FRONT SUPPORT E4340UD 1VM422518
B20 CUSHION E9TK4BD 1VM443501
B27 DUST COVER E3TK3FD 1VM331257
B28 DV EARTH PLATE E7C40UD 1VM425194
B29 FFC GUIDE E3NG0FD 1VM223899
B30 REAR HOLDER E3NG0FD 1VM325190D
B33 USB HOLDER E3TK0FD 1VM329013B
B34 USB EARTH PLATE E3TK0FD 1VM329052
B54 PCB CUSHION B E3TKABD 1VM443203
B55 HIMELON TAPE(6X80) E3TKABD 1VM443204A
FM1001 MOTOR DC FAN 2D65BK100230 MMEZR12XNR04
L1 SCREW TAP TIGHT M3X5 BIND HEAD+BLK NI GBHC3050
L4 SCREW TAP TIGHT M3X5 BIND HEAD+BLK NI GBHC3050
L5 SCREW P-TIGHT M3X6 BIND HEAD+ GBJP3060
L6 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
L7 SCREW P-TIGHT 3X14 BIND HEAD + GBJP3140
L8 SCREW C-TIGHT M3X6 E5610UD 0VM412937A
L10 SCREW S-TIGHT 3X8 H9210UD 0VM413320A
L11 SCREW S-TIGHT M3X10 BIND HEAD+ GBJS3100
L12 SCREW P-TIGHT M3*10 WASHERHEAD+ GCJP3100
L13 SCREW M3X4 M3X4 BIND+ (CR) SBC33040
L16 SCREW P-TIGHT M3X8 BIND HEAD+ BLK GBHP3080
L17 SCREW P-TIGHT M3X30 BIND HEAD+ GBJP3300
L18 S-TIGHT SCREW M3X6 BIND HEAD+BLACK GBHS3060
L19 SCREW S-TIGHT 3X8 H9210UD 0VM413320A
L20 SCREW M3X4 M3X4 BIND+ (CR) SBC33040
L22 SCREW S-TIGHT M3X6 CONE HEAD + GDJS3060
W2 WIRE ASSEMBLY 40PIN FFC WX1E3TKA-001 WX1E3TKA-001
W11 IEEE 1394 CABLE 330MM BLACK WPZ331SCP002
PACKING
S1 STYROFOAM E434AED 1VM120713F
S2 GIFT BOX CARTON E3TFGED 1VM343117
S3 SET BAG E3TK4BD 1VM433521C
S5 TOP PAD E434AED 1VM423574
S6 SIDE CARTON E3NG0FD 1VM428399
S7 BOTTOM PAD E434AED 1VM423575
ACCESSORIES
X1 REMOTE CONTROL UNIT NB847EH NB847EH
X2A! OWNERS MANUAL(EN) E3TFGEH 2VMN00012
X2B! OWNERS MANUAL(DE) E3TFGEH 2VMN00013
X2C! OWNERS MANUAL(PL) E3TFGEH 2VMN00014
X2D! OWNERS MANUAL(CS) E3TFGEH 2VMN00015
X5 BATTERY DRY R6 (SIZE AA ) XB00M0RKT002
X6 RF CORD PAL 1.2M WPZ0122LG001
X23 WARRANTY SHEET E3TF0ED 1VMN29433B
X26 OWNERS MANUAL CD-ROM E3TFGEH 2VMZ00026
X32 ACCESSORY BAG(430*210) E9TF3ED 1VM440100
Ref. No. Description Part No.
