FUNAI TD6D-M101 - Electrical Parts List

20130327 1-22-1 E3TFGEL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
DVD MECHANISM & DVD/HDD
MAIN CBA ASSEMBLY
SATA CBA UNIT
AV ASSEMBLY
AV CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
1B2 DVD MECHANISM & DVD/HDD MAIN CBA
ASSEMBLY
N78GSFEN
Ref. No. Description Part No.
SATA1 SATA CBA UNIT 2VSA00231
Ref. No. Description Part No.
AV ASSEMBLY
Consists of the following:
2VSA00224
AV1
DTV1
SEN1
AV CBA
DTV MODULE CBA UNIT
SENSOR CBA
----------
N76ETCEE
1VSA13519
Ref. No. Description Part No.
AV CBA
Consists of the following:
----------
CAPACITORS
C251 ELECTROLYTIC CAP. 10UF/16V/M/H7 CEC10RENW025
C252 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V CHD1JZ30F104
C253 CHIP CERAMIC CAP.(1608) B K 1000PF/50V CHD1JK30B102
C254 ELECTROLYTIC CAP. 1UF/50V/M/H7 CEF1R0ENW025
C301 CHIP CERAMIC CAP.(1608) B K 0.022UF/50V CHD1JK30B223
C302 ELECTROLYTIC CAP. 1UF/50V/M/H7 CEF1R0ENW025
C303 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V CHD1JZ30F104
C305 ELECTROLYTIC CAP. 1UF/50V/M/H7 CEF1R0ENW025
C306 CHIP CERAMIC CAP.(1608) B K 0.047UF/50V CHD1JK30B473
C307 CHIP CERAMIC CAP.(1608) B K 0.022UF/50V CHD1JK30B223
C308 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V CHD1JZ30F104
C311 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V CHD1JZ30F104
C312 ELECTROLYTIC CAP. 10UF/16V/M/H7 CEC10RENW025
C313 ELECTROLYTIC CAP. 1UF/50V/M/H7 CEF1R0ENW025
C314 CHIP CERAMIC CAP.(1608) B K 0.01UF/50V CHD1JK30B103
C315 CHIP CERAMIC CAP.(1608) B K 0.047UF/50V CHD1JK30B473
C316 ELECTROLYTIC CAP. 1UF/50V/M/H7 CEF1R0ENW025
C317 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V CHD1JZ30F104
C318 CHIP CERAMIC CAP.(1608) B K 0.022UF/50V CHD1JK30B223
C323 CHIP CERAMIC CAP.(1608) CH J 68PF/50V CHD1JJ3CH680
C324 CHIP CERAMIC CAP.(1608) B K 0.01UF/50V CHD1JK30B103
C325 CHIP CERAMIC CAP. B K 8200PF/50V CHD1JK30B822
C326 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V CHD1JZ30F104
C328 ELECTROLYTIC CAP. 47UF/6.3V/M/H7 CEA47RENW025
C329 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V CHD1JZ30F104
C331 ELECTROLYTIC CAP. 220UF/6.3V/M/H7 CEA221ENW025
C332 ELECTROLYTIC CAP. 100UF/16V M H7 CEC101ENW025
C333 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V CHD1JZ30F104
C334 ELECTROLYTIC CAP. 1UF/50V/M/H7 CEF1R0ENW025
C335 ELECTROLYTIC CAP. 100UF/6.3V/M/H7 CEA101ENW025
C336 CHIP CERAMIC CAP. CH J 220PF/50V CHD1JJ3CH221
C337 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V CHD1JZ30F104
C339 CHIP CERAMIC CAP. CH J 120PF/50V CHD1JJ3CH121
C340 ELECTROLYTIC CAP. 1UF/50V/M/H7 CEF1R0ENW025
C341 CHIP CERAMIC CAP.(1608) CH D 10PF/50V CHD1JD3CH100
C342 CHIP CERAMIC CAP.(1608) B K 1000PF/50V CHD1JK30B102
C343 ELECTROLYTIC CAP. 10UF/16V/M/H7 CEC10RENW025
C344 ELECTROLYTIC CAP. 4.7UF/25V M NP H7 CED4R7ENW050
C345 ELECTROLYTIC CAP. 0.47UF/50V/M/H7 CEFR47ENW025
C346 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V CHD1JZ30F104
C347 CHIP CERAMIC CAP.(1608) B K 0.1UF/25V CHD1EK30B104
C349 ELECTROLYTIC CAP. 0.47UF/50V/M/H7 CEFR47ENW025
C350 CAP CERAMIC (AX) 0.1UF/50V/F/Z CA1J104TU062
C370 CAP CERAMIC (AX) 0.01UF/16V/B/M CA1C103TU055
C371 CHIP CERAMIC CAP.(1608) B K 0.022UF/50V CHD1JK30B223
C372 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V CHD1JZ30F104
C373 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V CHD1JZ30F104
C374 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V CHD1JZ30F104
C375 CHIP CERAMIC CAP.(1608) B K 0.01UF/50V CHD1JK30B103
C376 CHIP CERAMIC CAP.(1608) B K 0.022UF/50V CHD1JK30B223
C377 CAP CERAMIC (AX) 0.01UF/50V/B/K CA1J103TU061
C378 CHIP CERAMIC CAP.(1608) B K 0.01UF/50V CHD1JK30B103
C379 ELECTROLYTIC CAP. 0.47UF/50V/M/H7 CEFR47ENW025
C381 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V CHD1JZ30F104
C382 CHIP CERAMIC CAP. B K 2200PF/50V CHD1JK30B222
C383 CHIP CERAMIC CAP. B K 2200PF/50V CHD1JK30B222
C384 ELECTROLYTIC CAP. 2.2UF/50V/M/H7 CEF2R2ENW025
C402 CAP POLYESTER FILM 0.018UF/100V J CA2A183SER02
C403 CERAMIC CAP. B K 470PF/100V CCD2AKS0B471
C404 ELECTROLYTIC CAP. 220UF/6.3V/M/H7 CEA221ENW025
C405 ELECTROLYTIC CAP. 47UF/6.3V/M/H7 CEA47RENW025
C407 CHIP CERAMIC CAP.(1608) B K 1000PF/50V CHD1JK30B102
C408 CHIP CERAMIC CAP. B K 1800PF/50V CHD1JK30B182
C409 CHIP CERAMIC CAP.(1608) CH J 33PF/50V CHD1JJ3CH330
C410 ELECTROLYTIC CAP. 10UF/16V/M/H7 CEC10RENW025
C411 CHIP CERAMIC CAP.(1608) B K 0.01UF/50V CHD1JK30B103
C412 ELECTROLYTIC CAP. 33UF/6.3V M H7 CEA33RENW025
C413 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V CHD1JZ30F104
C414 CHIP CERAMIC CAP.(1608) B K 0.022UF/50V CHD1JK30B223
C415 ELECTROLYTIC CAP. 4.7UF/25V/M/H7 CED4R7ENW025
C416 CHIP CERAMIC CAP.(1608) B K 4700PF/50V CHD1JK30B472
C417 ELECTROLYTIC CAP. 22UF/6.3V M H7 CEA22RENW025
C418 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V CHD1JZ30F104
C419 CHIP CERAMIC CAP. B K 220PF/50V CHD1JK30B221
C421 ELECTROLYTIC CAP. 47UF/6.3V/M/H7 CEA47RENW025
C452 ELECTROLYTIC CAP. 10UF/16V/M/H7 CEC10RENW025
C453 ELECTROLYTIC CAP. 22UF/10V/M/H7 CEB22RENW025
C454 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V CHD1JZ30F104
C455 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V CHD1JZ30F104
C456 ELECTROLYTIC CAP. 10UF/16V/M/H7 CEC10RENW025
C457 ELECTROLYTIC CAP. 4.7UF/25V/M/H7 CED4R7ENW025
C458 CHIP CERAMIC CAP.(1608) B K 0.01UF/50V CHD1JK30B103
C461 CHIP CERAMIC CAP.(1608) B K 0.01UF/50V CHD1JK30B103
C462 CHIP CERAMIC CAP.(1608) B K 4700PF/50V CHD1JK30B472
Ref. No. Description Part No.
