1-15-2 E9G00PIN
52 OUT
OSD-V-
OUT
OSD Video Signal Output
53 -
OSDVcc
+5V at Power On Signal
54 -
HLF
LPF Connected Terminal
(Slicer)
55
A,B -
NU Not Used
CIN
COLOR-
IN
SECAM or MESECAM
Chroma Video Input
Signal at Super Impose
56 -
NU Not Used
57 -
NU Not Used
58 IN
C-SYNC
Composite Synchronized
Pulse
59 OUT
8POUT-1
Control SCART 1 8Pin
Level by using 8POUT-1
and 8POUT-2
60 OUT
8POUT-2
Control SCART 1 8Pin
Level by using 8POUT-1
and 8POUT-2
61 -
NU Not Used
62 -
NU Not Used
63 OUT
SYSTEM-
RESET
System Reset Signal
64 IN
READY/
BUSY
Ready/Busy
communication Control
with Main Micro Controller
65 OUT
S-DATA-
OUT
Communication of Data
from VCR Micro
Controller
66 IN
S-DATA-
IN
Communication of Data
to VCR Micro Controller
67 OUT
S-CLOCK
Communication of Clock
with VCR Micro Controller
68 OUT
DRV-
DATA
VFD Driver IC Control
Data
69 OUT
DRV-STB
VFD Driver IC Chip Select
Signal
70 OUT
DRV-CLK
VFD Driver IC Control
Clock
71 OUT
IIC-BUS
SCL
IIC BUS Serial Clock
72
IN/
OUT
IIC-BUS
SDA
IIC BUS Serial Data
73 -
NU Not Used
74 -
NU Not Used
75
OUT P-ON-H Power On Signal to High
76 OUT
C-CONT
Capstan Motor Control
Signal
77 OUT
D-CONT
Drum Motor Control
Signal
78 OUT
C-F/R
Capstan Motor FWD/REV
Control Signal (FWD=“L”/
REV=“H”)
Pin
No.
Mark
IN/
OUT
Signal
Name
Function
79 IN
S-REEL
Supply Reel Rotation
Signal
80 IN
T- R E EL
Take Up Reel Rotation
Signal
81 OUT
LM-FWD/
REV
Loading Motor Control
Signal
82 OUT
OUTPUT-
SELECT
Output Select
83 OUT
VCR-
AUDIO-
MUTE
Audio Mute Control Signal
(Mute = “H”)
84 OUT
C-POW-
SW
Capstan Power Switching
Signal
85 IN
VCR-
POW-
SAFETY
VCR Power Supply Safety
Signal
86 IN
A-MODE
Hi-Fi Tape Detection
Signal
87 IN
C-FG
Capstan Motor Rotation
Detection Pulse
88 -
AMPVss Ground
89 IN
DVD-
POW-
SAFETY
DVD Power Supply Safety
Signal
90
IN
D-PFG
Drum PG/FG Input Signal
91 -
AMPVRE
F out
V-Ref for CTL AMP
92 -
AMPVRE
F in
V-Ref for CTL AMP
93 -
P80/C P80/C Terminal
94
IN/
OUT
CTL (-)
Playback/Record Control
Signal (-)
95
IN/
OUT
CTL (+)
Playback/Record Control
Signal (+)
96 -
AMPC
CTL AMP Connected
Terminal
97 -
CTL
To Monitor for CTL AMP
Output
98 -
AMPVcc
Always +5V with AC Plug
Connected
99 -
AVcc
Always +5V with AC Plug
Connected
100 IN
AGC
IF AGC Comparator
Signal
Pin
No.
Mark
IN/
OUT
Signal
Name
Function
