FUNAI W4A-A4180DB - Page 64

1-15-3 E9G00PIN
IC612 ( VFD DRIVER )
Pin
No.
IN/
OUT
Signal
Name
Name Function
1 OUT
POWER-
LED
Power LED Control Signal
2 OUT DVD-LED
DVD LED Control Signal
3 OUT VCR-LED
VCR LED Control Signal
4 -
NU
Not Used
5 IN OSC
Oscillator Input
6 -
NU
Not Used
7 IN DRV-DIN
DRV-Serial Data
8 IN DRV-CLK
DRV-Serial Clock
9 IN DRV-STB
DRV-Serial Interface
Strobe
10 -
NU
Not Used
11 -
NU
Not Used
12 - VSS
Ground
13 - VDD
+5V Power Supply
14 -
NU
Not Used
15 -
NU
Not Used
16 -
NU
Not Used
17 -
NU
Not Used
18 -
NU
Not Used
19 -
NU
Not Used
20
OUT
c
Segment Output
21 b
22 a
23 d
24 e
25 f
26 g
27 h
28 i
29 -
NU
Not Used
30 - VEE
Pull Down Level
31 -
NU
Not Used
32 -
NU
Not Used
33 -
NU
Not Used
34 -
NU
Not Used
35 -
NU
Not Used
36
OUT
7G
Grid Output
37 6G
38 5G
39 4G
40 3G
41 2G
42 1G
43 - VDD
+5V Power Supply
44 - VSS
Ground
