FUNAI W4A-A4180DB - Switches List; Connectors List (Continued); Diodes List (Continued); ICs List (Continued)

20070515 1-19-12 E9G00EL
POWER SW CBA
FUNCTION CBA
FRONT JACK CBA
RES CHIP 1608 1/10W J 16k Ω RRXA163YF002
R1720 CHIP RES. 1/10W J 33k Ω or RRXAJR5Z0333
RES CHIP 1608 1/10W J 33k Ω RRXA333YF002
R1721 CHIP RES. 1/10W J 33k Ω or RRXAJR5Z0333
RES CHIP 1608 1/10W J 33k Ω RRXA333YF002
R1722 CHIP RES. 1/10W J 18k Ω or RRXAJR5Z0183
RES CHIP 1608 1/10W J 18k Ω RRXA183YF002
R1723 CHIP RES. 1/10W J 27k Ω or RRXAJR5Z0273
RES CHIP 1608 1/10W J 27k Ω RRXA273YF002
R1724 CHIP RES. 1/10W J 15k Ω or RRXAJR5Z0153
RES CHIP 1608 1/10W J 15k Ω RRXA153YF002
R1725 CHIP RES. 1/10W J 33k Ω or RRXAJR5Z0333
RES CHIP 1608 1/10W J 33k Ω RRXA333YF002
R1726 CHIP RES. 1/10W J 18k Ω or RRXAJR5Z0183
RES CHIP 1608 1/10W J 18k Ω RRXA183YF002
R1727 CHIP RES. 1/10W J 27k Ω or RRXAJR5Z0273
RES CHIP 1608 1/10W J 27k Ω RRXA273YF002
R1728 CHIP RES. 1/10W J 15k Ω or RRXAJR5Z0153
RES CHIP 1608 1/10W J 15k Ω RRXA153YF002
R1729 CHIP RES. 1/10W J 33k Ω or RRXAJR5Z0333
RES CHIP 1608 1/10W J 33k Ω RRXA333YF002
SWITCHES
SW506 LEAF SWITCH MXS01830MVP0 SSC0101MCE03
SW507 SWITCH ROTARY SSS-53MD-1 SSR0106KB004
SW521 TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW522 TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW523 TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW524 TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW525 TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW526 TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW527 TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW528 TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW601 TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW603 TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW605 TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
MISCELLANEOUS
2B16 BUSH LED(F) H3700UD 0VM409508
2B17 SHIELD ASSEMBLY(T3 PAL) E3B90ED 1VM425280
2B46 ROHM HOLDER H7770JD 0VM304573
FL601 FL 7-BT-310N TVFD1C0FT056
JK1501 RCA JACK MSP-213V1-652-B NI L JXRL030LY116
JK1502 RGB CONNECTOR MRC-021V-05
ABS(B110
JXGL210LY008
JK1503 FIBER OPTIC TRANS.MODULE 0C-
0805T*002 or
JWHHA00JD002
Ref. No. Mark Description Part No.
OPTICAL TRANSMITTING MODULE
JST1162
JWHHA00SLT01
JK1504 RCA JACK MSP-281V41-B(B110) JXRL010LY140
JK1505 RCA JACK MSP-382V-12 NILF JXRL020LY120
JK1506 S TYPE JACK MDC-050V-2.4 LF(B110 or JXEL040LY003
S TYPE JACK DIN-425-01 JXEL040YUQ01
JW001 FLAT CABLE 4P AWG26#2651/P2.0/100 WX1E9B00-007
JW101 WIRE ASSEMBLY 30PIN FFC 30PIN/
150MM
WX1E9G00-002
JW102 WIRE ASSEMBLY 30PIN FFC 30PIN/
150MM
WX1E9G00-002
PS502 PHOTO INTERRUPTER RPI-302C70 QPWZP1302C70
RM1501 SENSOR REMOTE RECEIVER KSM-
602LU2S or
USESJRSKK048
REMOTE RECEIVER PIC-37042LU or USESJRSKK033
REMOTE RECEIVER MIM-93M6DKF USESJRSUNT01
TP301 PCB JUMPER D0.6-P17.0 JW17.0T
TP501 PCB JUMPER D0.6-P5.0 JW5.0T
TP503 PCB JUMPER D0.6-P7.0 JW7.0T
TP504 PCB JUMPER D0.6-P25.5 JW25.5T
TU1501 TUNER UNIT TMFE2-303A UTUNPLGAL020
VR501 CARBON P.O.T. VZ067TL1 B104 PB(F) VRCB104HH014
X301 XTAL 4.433619MHz or FXC445LLN004
XTAL 1K*044334EE FXC445LDS002
X501 QUARTS CRYSTAL 12.000000MHz or FXD126LCHE01
XTAL 12MHz 12.000MHz FXD126LDS002
X502 RESONATOR XTAL 32.768kHz QTF38-
32.768K125P15L or
FXC323LQUA03
XTAL DT38 32.768kHz FX0323LDS001
Ref. No. Mark Description Part No.
POWER SW CBA (MCV-B)
Consists of the following:
----------
DIODE
D671 LED(RED) 204HD/E NPQZ00204HDE
SWITCHES
SW671 TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
Ref. No. Mark Description Part No.
FUNCTION CBA (MCV-C)
Consists of the following:
----------
SWITCHES
SW681 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW682 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
MISCELLANEOUS
JW002 FLAT CABLE 3P AWG26#2651/P2.0/80 WX1E9B00-004
Ref. No. Mark Description Part No.
FRONT JACK CBA (MCV-D)
Consists of the following:
----------
CAPACITORS
C1205 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1206 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
CONNECTOR
CN1201 FE CONNECTOR TOP 8P 08FE-BT-VK-N JCFEJ08JG001
DIODES
D1544 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
Ref. No. Mark Description Part No.
