20070515 1-19-13 E9G00EL
SENSOR CBA
PSV CBA
POWER SUPPLY CBA
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1545 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1546 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1547 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
RESISTORS
R1201 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002
R1202 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002
R1203 CHIP RES. 1/10W J 220 Ω or RRXAJR5Z0221
RES CHIP 1608 1/10W J 220 Ω RRXA221YF002
R1204 CHIP RES. 1/10W J 220 Ω or RRXAJR5Z0221
RES CHIP 1608 1/10W J 220 Ω RRXA221YF002
R1205 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002
MISCELLANEOUS
JK1201 RCA JACK(YELLOW) MTJ-032-11B-40
FE01
JXRL010LY101
JK1202 RCA JACK(WHITE) MTJ-032-11B-41
FE01
JXRL010LY102
JK1203 RCA JACK(RED) MTJ-032-11A-31 FE01 JYRL010LY024
JK1204 S TYPE JACK MDC-050V-2.4 LF(B110 or JXEL040LY003
S TYPE JACK DIN-425-01 JXEL040YUQ01
JW103 FFC CABLE 8P FFC/P1.25/120 WX1E9700-002
Ref. No. Mark Description Part No.
SENSOR CBA
Consists of the following:
1VSA11699
TRANSISTORS
Q503 PHOTO TRANSISTOR PT204-6B-12 or NPWZT2046B12
PHOTO TRANSISTOR MID-32A22F NPWZ1D32A22F
Q504 PHOTO TRANSISTOR PT204-6B-12 or NPWZT2046B12
PHOTO TRANSISTOR MID-32A22F NPWZ1D32A22F
Ref. No. Mark Description Part No.
PSV CBA
Consists of the following
1VSA15996
POWER SUPPLY CBA (PSV-A)
REAR JACK CBA (PSV-B)
----------
----------
Ref. No. Mark Description Part No.
POWER SUPPLY CBA (PSV-A)
Consists of the following:
----------
CAPACITORS
C013 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
CAP ELECTROLYTIC 10µF/50V/M CA1J100ENE12
C014 ELECTROLYTIC CAP. 470µF/16V M or CE1CMASDL471
CAP ELECTROLYTIC 470µF/16V/M CA1C471ENE12
C015 ELECTROLYTIC CAP. 100µF/16V M or CE1CMASDL101
CAP ELECTROLYTIC 100µF/16V/M CA1C101ENE12
C016 ELECTROLYTIC CAP. 2200µF/6.3V SL or CE0KMZADL222
ELECTROLYTIC CAP. 2200µF/6.3V M or CE0KMZPDL222
CAP ELECTROLYTIC 2200µF/6.3V/M CA0K222ENE11
C017 ELECTROLYTIC CAP. 2200µF/6.3V SL or CE0KMZADL222
ELECTROLYTIC CAP. 2200µF/6.3V M or CE0KMZPDL222
CAP ELECTROLYTIC 2200µF/6.3V/M CA0K222ENE11
C018 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
Ref. No. Mark Description Part No.
CAP ELECTROLYTIC 470µF/6.3V/M CA0K471ENE12
C020 ELECTROLYTIC CAP. 22µF/50V M or CE1JMASDL220
CAP ELECTROLYTIC 22µF/50V/M CA1J220ENE12
C022 ELECTROLYTIC CAP. 470µF/35V M or CE1GMASDL471
CAP ELECTROLYTIC 470µF/35V/M CA1G471ENE12
C1001! ACROSS THE LINE CAP. 0.068µF/250V
or
CT2E683DC016
! METALIZED FILM CAP. 0.068µF/250V M CT2E683MS037
C1004 ELECTROLYTIC CAP. 100µF/400V M CA2H101S6016
C1005 CERAMIC CAP. SL K 56pF/1KV or CCD3AKPSL560
CERAMIC CAP. SL J 56pF/1KV CCD3AJPSL560
C1006! SAFTY CAP. 2200pF/250V or CCN2EMA0E222
! SAFETY CAP. 2200pF/250V CA2E222MR049
C1007 ELECTROLYTIC CAP. 1000µF/6.3V M or CE0KMASDL102
CAP ELECTROLYTIC 1000µF/6.3V/M CA0K102ENE12
C1013 CERAMIC CAP.(AX) B J 1000pF/50V CCA1JJT0B102
C1018 ELECTROLYTIC CAP. 100µF/10V M or CE1AMASDL101
CAP ELECTROLYTIC 100µF/10V/M CA1A101ENE12
C1021 CERAMIC CAP.(AX) Y M 0.01µF/16V CCA1CMT0Y103
C1025 CERAMIC CAP.(AX) B K 0.01µF/50V CCA1JKT0B103
C1029 CERAMIC CAP.(AX) X K 1800pF/16V CCA1CKT0X182
C1032 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
CAP ELECTROLYTIC 47µF/16V/M CA1C470ENE12
C1033 CERAMIC CAP. YV Z 0.022µF/50V CCD1JZSYV223
C1035 ELECTROLYTIC CAP. 3300µF/6.3V SL or CE0KMZADL332
ELECTROLYTIC CAP. 3300µF/6.3V SM or CE0KMZPDL332
CAP ELECTROLYTIC 3300µF/6.3V/M CA0K332ENE11
C1036 CERAMIC CAP. B K 470pF/500V CCD2JKP0B471
C1037 ELECTROLYTIC CAP. 1000µF/16V M or CE1CMASDL102
CAP ELECTROLYTIC 1000µF/16V/M CA1C102ENE11
C1039 ELECTROLYTIC CAP. 470µF/16V M or CE1CMASDL471
CAP ELECTROLYTIC 470µF/16V/M CA1C471ENE12
C1106 ELECTROLYTIC CAP. 100µF/35V M or CE1GMASDL101
CAP ELECTROLYTIC 100µF/35V/M CA1G101ENE12
C2014 CERAMIC CAP. B K 0.01µF/500V CCD2JKP0B103
DIODES
D013 RECTIFIER DIODE BA158 or NDQZ000BA158
DIODE FAST RECOVERY BA158 or NDLZ00BA158S
RECTIFIER DIODE BA158 NDWZ000BA158
D014 SCHOTTKY BARRIER DIODE SB190 or NDQZ000SB190
DIODE SCHOTTKY SB190 or NDLZ00SB190S
SCHOTTKY BARRIER DIODE SB190 NDWZ000SB190
D015 ZENER DIODE MTZJT-776.8B or QDTB0MTZJ6R8
DIODE ZENER 6V8BSB-T26 or NDTB6R8BST26
ZENER DIODE DZ-6.8BSBT265 NDTB0DZ6R8BS
D016 SCHOTTKY BARRIER DIODE SB340 or NDQZ000SB340
DIODE SCHOTTKY SB340 or NDLZ00SB340S
SCHOTTKY BARRIER DIODE SB340 NDWZ000SB340
D017 ZENER DIODE MTZJT-7715C or QDTC00MTZJ15
DIODE ZENER 15BSC-T26 or NDTC015BST26
ZENER DIODE DZ-15BSCT265 NDTC00DZ15BS
D018 RECTIFIER DIODE BA158 or NDQZ000BA158
DIODE FAST RECOVERY BA158 or NDLZ00BA158S
RECTIFIER DIODE BA158 NDWZ000BA158
D019 RECTIFIER DIODE FR203-B/P or NDQZ000FR203
DIODE FAST FR203 NDLZ00FR203S
D1001 DIODE 1N5397-B or NDLZ001N5397
DIODE RECTIFIER IN5397 or NDLZ01N5397S
DIODE 1N5397BD NDL1001N5397
D1002 DIODE 1N5397-B or NDLZ001N5397
DIODE RECTIFIER IN5397 or NDLZ01N5397S
DIODE 1N5397BD NDL1001N5397
D1003 DIODE 1N5397-B or NDLZ001N5397
DIODE RECTIFIER IN5397 or NDLZ01N5397S
DIODE 1N5397BD NDL1001N5397
D1004 DIODE 1N5397-B or NDLZ001N5397
DIODE RECTIFIER IN5397 or NDLZ01N5397S
Ref. No. Mark Description Part No.
To Next Page
