FUNAI W4A-A4180DB - ICs List (Continued); Coils List (Continued); Resistors List (Continued); Miscellaneous Parts List (Continued)

20070515 1-19-14 E9G00EL
DIODE 1N5397BD NDL1001N5397
D1006 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1008 SCHOTTKY BARRIER DIODE SB140 or NDQZ000SB140
DIODE SCHOTTKY SB140 or NDLZ00SB140S
SCHOTTKY BARRIER DIODE SB140 NDWZ000SB140
D1011 RECTIFIER DIODE BA159 or NDQZ000BA159
DIODE FAST RECOVERY BA159 or NDLZ00BA159S
RECTIFIER DIODE BA159 NDWZ000BA159
D1012 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1016 SCHOTTKY BARRIER DIODE SB140 or NDQZ000SB140
DIODE SCHOTTKY SB140 or NDLZ00SB140S
SCHOTTKY BARRIER DIODE SB140 NDWZ000SB140
D1017 ZENER DIODE MTZJT-7720A or QDTA00MTZJ20
DIODE ZENER 20BSA-T26 or NDTA020BST26
ZENER DIODE DZ-20BSAT265 NDTA00DZ20BS
D1018 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1019 ZENER DIODE MTZJT-776.8B or QDTB0MTZJ6R8
DIODE ZENER 6V8BSB-T26 or NDTB6R8BST26
ZENER DIODE DZ-6.8BSBT265 NDTB0DZ6R8BS
D1022 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1023 PCB JUMPER D0.6-P5.0 JW5.0T
D1024 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1025 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1030 SCHOTTKY BARRIER DIODE SB240-B/
P or
NDQZ000SB240
DIODE SCHOTTKY SB240 or NDLZ00SB240S
SCHOTTKY BARRIER DIODE SB240-B/
P
NDWZ000SB240
D1031 SCHOTTKY BARRIER DIODE SB390 or NDQZ000SB390
DIODE SCHOTTKY SB390 or NDLZ00SB390S
SCHOTTKY BARRIER DIODE SB390 NDWZ000SB390
D1032 SCHOTTKY BARRIER DIODE SB340 or NDQZ000SB340
DIODE SCHOTTKY SB340 or NDLZ00SB340S
SCHOTTKY BARRIER DIODE SB340 NDWZ000SB340
ICS
IC1001
!
PHOTOCOUPLER EL817A or NPEA000EL817
! PHOTOCOUPLER EL817B or NPEB000EL817
! PHOTOCOUPLER PS2561A-1(Q) or QPEQPS2561A1
! PHOTOCOUPLER PS2561A-1(W) QPEWPS2561A1
COILS
L010 RADIAL TYPE CHOKE COIL CW68-
470K-841040NP or
LLBD00PKV023
CHOKE COIL 47µH or LLBD00PKV022
CHOKE COIL 47µH-K LLBD00PKT001
L013 RADIAL TYPE CHOKE COIL CW68-
470K-841040NP or
LLBD00PKV023
CHOKE COIL 47µH or LLBD00PKV022
CHOKE COIL 47µH-K LLBD00PKT001
L1001 BEAD CORE ASSEMBLY E9GA0BD 1VSA15812
L1002 BEAD CORE ASSEMBLY E9GA0BD 1VSA15812
L1003! LINE FILTER 56MH TLF14CB5630R2 or LLBG00ZTU022
! LINE FILTER 50MH LF-4D-E503(PB
FREE)
LLBG00ZKQ014
L1004 BEAD CORE B16 RH 3.5X10X1.3 or XL03010XM001
BEAD CORE HF70BB3.5X10X1.3 XL03010TE001
L1005 BEAD CORE ASSEMBLY E9GA0BD 1VSA15812
Ref. No. Mark Description Part No.
L1011 RADIAL TYPE CHOKE COIL CW68-
470K-841040NP or
LLBD00PKV023
CHOKE COIL 47µH or LLBD00PKV022
CHOKE COIL 47µH-K LLBD00PKT001
L1013 POWER INDUCTORS CWKBNP-180K or LLF1800KV002
POWER INDUCTORS TWKBNP-180K or LLC180KKV007
CHOKE COIL(18µH) LHL10NB180K LLARKGQTU180
TRANSISTORS
Q1001! FET 2SK3566 QFWZ02SK3566
Q1003 TRANSISTOR 2SC1815-Y(TE2 F T) QQSY2SC1815F
Q1004 TRANSISTOR KTA1267-Y-AT/P or NQSYKTA1267P
TRANSISTOR KTA1267-GR-AT/P NQS1KTA1267P
Q1008 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F
TRANSISTOR 2SC1815-GR(TE2 F T) QQS12SC1815F
RESISTORS
R057 CARBON RES. 1/6W J 220k Ω or RCX6JATZ0224
CARBON RES. 1/4W J 220k Ω RCX4JATZ0224
R1002 CARBON RES. 1/4W J 560k Ω RCX4JATZ0564
R1003 CARBON RES. 1/4W J 680k Ω RCX4JATZ0684
R1004 METAL OXIDE FILM RES. 2W J 82k Ω or RN02JZLZ0823
METAL OXIDE FILM RES. 2W J 82k Ω RN02JZPZ0823
R1005 CARBON RES. 1/4W J 1M Ω RCX4JATZ0105
R1006 CARBON RES. 1/4W J 1M Ω RCX4JATZ0105
R1007 CARBON RES. 1/4W J 1M Ω RCX4JATZ0105
R1008 CARBON RES. 1/4W G 820 Ω RCX4GATZ0821
R1010 CARBON RES. 1/6W J 22k Ω or RCX6JATZ0223
CARBON RES. 1/4W J 22k Ω RCX4JATZ0223
R1011 METAL OXIDE FILM RES. 1W J 1.3 Ω or RN01JZLZ01R3
METAL OXIDE FILM RES. 1W J 1.3 Ω RN01JZPZ01R3
R1020 CARBON RES. 1/6W J 1.8k Ω or RCX6JATZ0182
CARBON RES. 1/4W J 1.8k Ω RCX4JATZ0182
R1021 CARBON RES. 1/6W J 1k Ω or RCX6JATZ0102
CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1022 CARBON RES. 1/6W J 4.7k Ω or RCX6JATZ0472
CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R1023 CARBON RES. 1/6W G 2.2k Ω or RCX6GATZ0222
CARBON RES. 1/4W G 2.2k Ω RCX4GATZ0222
R1024 CARBON RES. 1/6W J 68k Ω or RCX6JATZ0683
CARBON RES. 1/4W J 68k Ω RCX4JATZ0683
R1025 CARBON RES. 1/6W G 5.6k Ω or RCX6GATZ0562
CARBON RES. 1/4W G 5.6k Ω RCX4GATZ0562
R1029 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1032 CARBON RES. 1/6W J 2.2k Ω or RCX6JATZ0222
CARBON RES. 1/4W J 2.2k Ω RCX4JATZ0222
R1035 CARBON RES. 1/6W J 1k Ω or RCX6JATZ0102
CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1036 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1037 CARBON RES. 1/6W J 10k Ω or RCX6JATZ0103
CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R1038 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1039 CARBON RES. 1/6W J 470k Ω or RCX6JATZ0474
CARBON RES. 1/4W J 470k Ω RCX4JATZ0474
R1040 CARBON RES. 1/4W J 10 Ω RCX4JATZ0100
R1041 CARBON RES. 1/4W J 10 Ω RCX4JATZ0100
R1043 METAL OXIDE FILM RES. 1W J 2.7 Ω or RN012R7ZU001
METAL OXIDE FILM RES. 1W J 2.7 Ω RN012R7DP003
R1058 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1059 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1126 CARBON RES. 1/6W J 33k Ω or RCX6JATZ0333
CARBON RES. 1/4W J 33k Ω RCX4JATZ0333
MISCELLANEOUS
2B18 HEAT SINK E6800ED 1VM420987
Ref. No. Mark Description Part No.
