bintec User’s Guide System
Submenu External Activity Monitor
■ Start and configure the Windows application on your PC (see BRICKware
for Windows).
The EXTERNAL ACTIVITY MONITOR menu consists of the following fields:
Table 2-1: EXTERNAL ACTIVITY MONITOR menu fields
Field Description
Client IP Address IP address to which the gateway sends the
UDP packets.
The default value 255.255.255.255 means that
the broadcast address of the first LAN interface
is used.
Client UDP Port Port number for the bintec Activity Monitor
(default value:
2107, registered by IANA - Inter-
net Assigned Numbers Authority).
Type Type of information sent in the UDP packets to
the Windows application. Possible values:
■ off: Deactivates the Activity Monitor (de-
fault value)
■ physical: Only information about physical
interfaces
■ physical_virt: Information about physical
and virtual interfaces
Update Interval (sec) Update interval in seconds. Possible values: 0
to
60 (default value: 5).
The value 0 deactivates the function.
