Submenu External Activity Monitor
2
2 Submenu
External Activity Monitor
The fields of the EXTERNAL ACTIVITY MONITOR submenu are described below.
The SYSTEM ➜ EXTERNAL ACTIVITY MONITOR menu contains the settings neces-
sary for monitoring your gateway with the Windows Activity Monitor tool (part of
BRICKware for Windows).
Purpose The Activity Monitor enables Windows users to monitor the activities of the
gateway. Important information about the status of physical interfaces (e.g.
ISDN line) and virtual interfaces (e.g. WAN partner) is easily obtained with one
tool. A permanent overview of the utilization of the gateway is possible.
Method of operation A Status Daemon collects information about the gateway and transfers it in the
form of UDP packets to the broadcast address of the first LAN interface (default
setting) or to an explicitly entered IP address. One packet is sent per time inter
-
val, which can be adjusted individually to values from 1 - 60 seconds. Up to 100
physical and virtual interfaces can be monitored, provided the packet size of
4,096 bytes is not exceeded. The Activity Monitor on your PC receives the pack
-
ets and can display the information contained in them in various ways according
to configuration.
Activate the Activity Monitor as follows:
■ Configure the relevant gateway(s) to be monitored.
R232bw Setup Tool Funkwerk Enterprise Communications GmbH
[SYSTEM]: [ACTIVMON]: External Activity Monitor MyGateway
Client IP Address 255.255.255.255
Client UDP Port 2107
Type off
Update Interval (sec) 5
SAVE CANCEL
To Next Page
