BEARING / Axle Replacement
step 8 :
step 9 :
06
MAMBA PEDALS
MAMBA PEDALS 2024.04.22 / REV. 0
Position the new bushing on the bushing press. Then, gently tap the bushing press with
a plastic hammer to install the new bushing.
Apply grease on the interface between the side cap and the bearing’s outer race. Push the
new bearing into the pedal by tightening the side cap into the pedal. Make sure the side
cap absolutely bottoms out to make sure the bearing is properly seated.
6mm hex key
5-6Nm
Bearing
