BEARING / Axle Replacement
step 6 :
step 7 :
05
MAMBA PEDALS
MAMBA PEDALS 2024.04.22 / REV. 0
Push and screw the bushing remover tool into the bushing within the pedal body. Once
the remover is fully engaged with the bushing, pull it out to remove the bushing.
To extract the bushing from the pedal body, secure the pedal body in a vise. It's advisable
to place a cloth between the pedal body and the vise to protect the pedal's surface.
