ii
CAUTION
Turn off the POWER switch on the hull
unit before using the hand crank.
Bodily injury can result if the hand crank
rotates unexpectedly, because the raise/
lower motor may start up.
Observe the following compass safe
distances to prevent interference to a
magnetic compass:
Standard
compass
Steering
compass
Processor
unit
0.4 m
0.3 m
Observing the following speed limits
when testing the equipment at sea trial:
Raising/lowering transducer: 16 kts max.
Transducer completely lowered: 18 kts max.
Exceeding above limits will damage the
equipment and void the warranty.
The zinc block near the transducer must
be replaced yeary.
The junction between the transducer and
main shaft may corrode, which can result
in loss of the transducer or water leakage
inside the ship. Replace the zinc block
yeary.
CAUTION
Attach protection
earth
securely
to the ship's body.
The protection earth is required
to the transceiver unit and DC-AC
inverter (option) to prevent
electrical shock.
Control
unit
Transceiver
unit
DC-AC
inverter
0.3 m
0.3 m
1.4 m
1.05 m
1.4 m
0.9 m
To Next Page
