iii
SYSTEM CONFIGURATION
Hull Unit
CSH-8040
600 mm stroke,
CSH-8041
400 mm stroke
Transceiver Unit
CSH-8030-8L
Ship's Mains
100 VAC/
115 VAC/
200 VAC/
220 VAC/
240 VAC/
1 ,50-60Hz
DC/AC
Inverter
TR-2451
24/32VDC
Junction Box
Motion Sensor
MS-100
: Standard supply
: Option
: User supply
Processor Unit
CSH-5210
Control Unit
CSH-5211
Navaid
Current Indicator
AD Converter
Speed Log
E/S Interface
Remote Controller
Speaker
Display Unit (MU-150C, etc)
(2 max.)
CSH-1700
