3. TARGET TRACKING (TT)
3-25
3.16.7 How to change the acquisition zone reference
The acquisition zone can be referenced to heading or North using the following pro-
cedure:
1. Open the menu.
2. Select [5 TT•AIS].
3. Select [2 ACQUISITION ZONE].
4. Select [4 AZ STABILIZATION].
5. Select [STAB HDG] to reference heading, or [STAB NORTH] to reference North.
6. Close the menu.
3.16.8 How to set acquisition zone shape and stabilization (B/W-
types only)
The shape of the No. 2 acquisition zone can be a sector or a polygon having up to 10
points. (The shape of the No.1 acquisition zone is always a sector.)
1. Open the menu.
2. Select [5 TT•AIS].
3. Select [2 ACQUISITION ZONE].
4. Select [5 AZ POLYGON].
5. Select the appropriate setting.
*: Shown only for B/W-type.
6. Close the menu.
Setting Description
[OFF] Acquisition zone is a sector; number of points is limited to four.
Stabilized against land.
[STAB GND] Polygon having 3-10 points. Stabilized against ground.
[STAB HDG] Polygon having 3-10 points. Stabilized against heading.
[STAB NORTH] Polygon having 3-10 points. Stabilized against North.
[AROUND
CHECK AREA]*
Sets a check area around own ship. See the topic on the follow-
ing page for details and settings.
