2.2 Scanner Unit
2-30
2.2.4 F
A
R-2827SW scanner unit
Fig. 2.
2.33 RSB-104 with Cover Removed
Fig. 2.
2.34 RSB-104 with Cover Removed
Antenna Switch
W
aveguide F
lange
MSS-7497 Board
TB for Antenna Motor Power Supply
Performance Monitor Antenna
Performance Monitor (PM-51)
145
147
