Furuno FELCOM 12 Installation Manual

5
7. Coat bolts with sealant (supplied)
Figure3-6 Antenna unit mounting
Apply sealant all over the
volt/washers/crimp- on lug.
Figure 3-7 Coating bolts with sealant
Note 1: Be sure no sealant enters the bolt hole
of the ground terminal
Note 2: The "antenna installation materials Kit"
(optional supply) is available to fix the
antennamounting pipe to an antenna mast.
Antenna installation materials (option)
Type: CP16-01512
Code. number: 004-437-300
Table 3-2 Optional antenna inst. materials
emaNepyTytQ
1pmalcesoH303SUS0836.oN2
2
daehlavO
wercs
W0072C21x3M6
31erutxifepiP1602-310-611
42erutxifepiP2602-310-612
*
After connnecting, wrap
connector with self-
bonding tape and then
vinyl tape. Bind the tape
end with a cable tie.
*
POLE DIAMETER
(Ø60-90)
HOSE CLAMP
x 2
PIPE
FIXTURE 1
PIPE
FIXTURE 2
: Antenna
installation
Materials
*
*
Figure 3-8 Mounting the antenna with
optional antenna installation materials
Communication unit
1. Fix the hanger on a table with six tapping
screws.
237
79
82
Figure 3-9 Hanger for communication unit
2. Set knobs and washers to communication
unit. Set the communication unit to the
hanger and tighten knobs.
Antenna
mounting
pipe
Ground wire
(370 mm)
Ground stud
After connnecting, wrap
connector with self-bonding
tape and then vinyl tape.
Bind the tape end with a cable
tie. Then fasten the connector
with cable band.
Tape here to prevent
cable damage.
Fasten the cable with
cable bands.
Apply sealant
Antenna Mast
