2-28
INPUT/OUTPUT Data to/from SPU Board (03P9230)
Signal Name
Port Name
I; input,
O: output
Signal Format
Equipment
Connectable
Remarks
Heading J206 (I)
AD10 format,
25 msec
GC-1/2/6/7/8,
AD-10/10S/100
Generating HM, NU/TM modes
, True EBL, True vector
(E-PLOT), signal processing
1/2/3, True echo trait, ARP-17.
Heading J208 (I)
NMEA-0183 V2.0
(current loop)
PG-1000, etc
Generating HM, NU/TM mo
des, True EBL, True vector
(E-PLOT), signal processing
1/2/3, True echo trait.
J210 (I) Contact closure
DS-30/70
CI-30/60/80
GP-500/500MK2
Ship’s speed data, TM
mode, True v ector (E-PLOT),
signal processing 1/2/3,
True echo trait, ARP-17.
Speed
Nav data
J202 (I/O)
J203 (I/O)
NMEA-0183 V2.0
(current loop)
IEC 61162
(RS-422, level)
GP-70MK2/80
GP-500MK2
J202 (Input): L/L, SPD, CRS,
cursor L/L, date,
time, depth, etc.
J202 (Output):RATLL, RAOSD
J203 (Input): Current, depth,
and heading
J203 (Output):Input from J202
Slave display J204 (O)
TRUE-TRIG,
VIDEO,
TRUE-HD, BP
Timing between TRUE-TRIG
and VIDEO adjusted, HD ad-
justed, BP:360 pulse/rotation.
Slave display J205 (I)
TRUE-TRIG,
VIDEO,
TRUE-HD, BP
Radars having
slave func-tion
Timing between TRUE-TRIG
and VIDEO adjusted, HD ad-
justed, BP:360 pluse/rotation.
Remote
display
J108 (O)
R, G, B,
H-SYNC, V-SYNC
PC monitor
or Hard copier
Buffer Board (03P9229)
required
External
Buzzer
(AC/DC)
J211 (O) +12 V Suppied locally 150 mA Max.
I/F PWR J212 (O)
+5 V, -12 V,
+12 V
+5 V : 100 mA
+12 V : 200 mA
-12 V : 200mA
INPUT/OUTPUT Signal of ARP-17 Board (18P9004)/ARP-10 (18P9007)
Signal Name
Port Name
I; input,
O: output
Signal Format
Equipment
Connectable
Remarks
RS-422
18P9004
J2 (O)
RS-422, level
PC
$RATTM
(ARPA:Tracked Target Data)
Current loop
18P9007
J3 (O)
Current loop PC
$RATTM
(ARPA:Tracked Target Data)
INPUT/OUTPUT of MAIN PANEL Board (03P9247)
Signal Name
Port Name
I; input,
O: output
Signal Format
Equipment
Connectable
Remarks
RS-232C
J305 (I/O)
RS-232C, level
PC
Program updating
To Next Page
