v
SYSTEM CONFIGURATION
SC-30
12-24 VDC
: Standard supply
: Optional supply
: Local supply
IF-NMEASC
INTERFACE UNIT
Video Plotter
Radar
Autopilot
Current Indicator
Scanning Sonar
Video Sounder
ECDIS
AIS
NavNet 3
(MFD, MFDBB)
OR
NMEA-2000
NMEA-0183
Marine Instrument
Junction Box
IF-NMEASC
