-4.3-
DIGITAL AUDIO
LED INTF
24 VDC
ANALOG
VGA CPU
SERIAL 1 COM 1, COM 2 (top)
SERIAL 2 (to add extra serial 8 channels)
Main Control Unit, Rear view
PDU Board AC/DC power pack
BNC connectors Batteries LED Board Breaker switches
for radar video
Power Distribution Unit (PDU) with cover removed
FIREWIRE
Hard disk (top) and
DRU (bottom)
VIDEO
(VD1, VD2, VD3 and
VD4 from bottom)
