Fusion SG-DA41400 User Manual

3
CROSSOVER TABLE
Crossover Type Crossover Frequency Bass Boost
Zone 1 Selectable - LPF, HPF, or
FULL
LPF or HPF Tunable -
32Hz - 320Hz
Zone 2 Selectable - LPF, HPF, or
FULL
LPF or HPF Tunable -
32Hz - 320Hz
Tunable - 0dB -
12dB
TROUBLE SHOOTING
Problem Possible
Reason
Solution
Amplier not
switching on.
Power LED not ‘on’.
No +12v to power
wire
No power to remote
wire
Fuse broken
Fuse on amplier
blown
Check fuses and connections to battery
Check remote on connections to head unit
Replace fuse with correct type and
amperage
Replace fuse with correct type and
amperage
Amplier not
working, but Power
LED is ‘on’
Amplier too hot
Speaker wires
shorted
Move amplier to vented area
Turn head unit down
Check that there are no speaker wires
shorted to other wires
No Sound No RCA Signal
Gain control not
set up
Head Unit off or low
vol
Amplier
Speakers
Check RCA connection to head unit
Ensure you have set up the amplier gain
level control
Check head unit volume level
Check all power, remote on and ground
Check connections
Check speaker connections
1. Turn the amplier level to zero
2. Turn the volume of the head unit to 3/4
and the tone settings to zero
3. Adjust the level control until the desired
RCA INPUTS
Choose the correct length RCA cable & run them to the RCA outputs of the source/head unit,
avoiding running beside other looms & or power cable.
LEVEL CONTROL
This control is used to match the input level of the amplier to the output level of the head unit.
We recommend the following method. NOTE: Remove screws and the top cover of amplier to
access controls.
maximum volume is achieved without
distortion.
4. Failure to follow these steps may cause
permanent damage to the audio system.
