AMPLIFIER DIMENSIONS
All dimensions provided are in millimeters (mm) unless indicated
CONTROL DESCRIPTIONS
300
11-13/16"
268
10-9/16"
210
8-9/32"
160
6-5/16"
6.5
1/4"
50
1-31/32"
12
15/32"
1. SPEAKER OUTPUT:
Connect your speakers to these terminals.
2. RCA OUTPUT:
Use these RCA connectors to connect to a secondary
amplier. This output is a pass-thru connection derived
from the RCA input connectors so that the signal level
and frequency response is the same as the original input
signal.
3. ZONE 2 RCA INPUT:
Connect these RCA connectors to a head unit with low
level output connection.
4. ZONE 1 RCA INPUT:
Connect these RCA connectors to a head unit with low
level output connection.
300
11-13/16"
268
10-9/16"
210
8-9/32"
160
6-5/16"
6
.
5
1
/4
"
Z2R
Z2L
Z2LZ2RZ1LZ1R
Z1R
Z1L
1 2 3 4 5 6 7 8 9
