FUTABA GY601 - Transmitter ATV Function for Gain Adjustment

28
DATA SETTING
When Using a Transmitter ATV Function
The ATV function lets operator perform a gain adjustment at each CH5
switch position.
[GY601 Settings]
Select the gyro operation mode at the GY601 Mode screen. (AVC, NOR,
or CMT)
[Transmitter Settings]
ATV function:
Set the ATV rates at the transmitter CH5 ATV function.
[Sensitivity Display]
The gain display indicates the actual gain at the GY601 normal screen
display. The following shows the relationship between transmitter and gyro
setting.
- Relationship between transmitter and gyro setting
Transmitter
settings
GY601mode
settings
Actual gain
ATV rates
NOR
AVC
CMT
CH5 Switch CH5 Switch
Forward side Front side
90% - 0% - 90%
Normal mode Normal mode
AVCS mode AVCS mode
Normal mode AVCS mode
(G2) (G1)
100% - 0% - 100%
