Displaying data from the Distance Screen
The Distance screen displays and sets altitude data
from an SBS-01/02G GPS Sensor (sold separately),
and allows the distance to the airborne aircraft to
be read by the transmitter. When the aircraft flies
inside or outside the set distance, an alarm and
vibration alerts the pilot.
*The GPS sensor is necessary, and is sold separately. Mount and
connect the sensor in accordance with the sensor instruction
manual.
*AGPSsensormustbeinstalledintheaircraft.
Setsthedistance
onwhichthealarm
operates.
●
Tap the [GPS] button in the Telemetry screen to call the
setup screen shown below.
Max.andmin.values
sincethepowerwas
turnedONwilldisplay.
Distance
Alarmischosenfrom
Buzzer,Voice,and
Inhibit.
AllowsSpeechtobe
turnedONorOFF.
↑Anupwardarrow
indicatesthealarm
willsoundwhenthe
distancereachesabove
yoursetvalue.
↓Adownwardarrow
indicatesthealarm
willsoundwhenthe
distancereachesbelow
yoursetvalue.
Taptothe[Preset]of"Reference"item.
Setsthecurrentaircraftpositionasthe
startingpoint.
Surface
Altitude
Slant
Altitudecalculatedaseitherstraightlinedistance(slant)or
surfacedistanceonamapcanalsobeselected.
Select<Slant><Surface>to"Distancemode",tapthe
screen.
Type1
Type2
Type3
"Vibrator"type
Ifthefollowingtypesareselected,thetransmitter
willvibrateduringthewarning.
●
