110
ڀ ŪŲŃƗƒŃŷŤťůŨŃŲũŃŦŲűŷŨűŷŶ
Alarmischosenfrom
Buzzer,Voice,and
Inhibit.
AllowsSpeechtobe
turnedONorOFF.
↑Anupwardarrow
indicatesthealarm
willsoundwhenthe
currentreachesabove
yoursetvalue.
↓Adownwardarrow
indicatesthealarm
willsoundwhenthe
currentreachesbelow
yoursetvalue.
*Thecurrentandcapacityconsumptiondisplaymayvary
dependingontheusageconditions,souseitasaguide.
◆ ESCtelemetrydisplayscreen
TheESCstatusisdisplayed.Alarmsettingisalsopossible.
Displaymax/minvalue
Pressandholdtoreset.
Displaymax/minvalue
Pressandholdtoreset.
Taptomovetothe
currentsettingpage.
Taptomovetothe
voltagesettingpage.
Taptomovetothe
capacitysettingpage.
Taptomovetothe
rotationsettingpage.
Enterthenumberof
polesforyourmotor.
Whenenabled,thealarm
willbeactivatedinthe
followingwarningstate.
Ifthegearisdown,enter
thegearratiotodisplay
thehelicopterrotorspeed
andtheairplanegeardown
propellerspeed.
Whenenabled,thevibrator
willstartinthefollowing
warningstate.
◆ Warningstate
◆ AlarmscanbesetforVoltage,Capacity,Rotation,ESCtemperature,andThrottleusing
thesameprocedure.
ShowstheoutputlevelfromtheESC
tothemotor,notthepositionofthe
throttlestick.
Evenifthestickisinthe50%
position,theoutputmaynotbe50%
dependingontheESCsetting.
Throttlenotat0%
Lowvoltage
Overtemperature
Overcurrent
Motorlocked
Throttlesignallost
WhenthethrottlestickisnotlowwhenESCisstarted
Whenthebatteryvoltageisbelowthecutoffvoltage
WhentheESCtemperatureis110°Corhigher
Peakcurrentover
Whenthemotorlocks
Whennothrottlesignalisreceivedformorethan0.25s
Taptomovetothe
temperaturesettingpage.
Taptomovetothethrottlesetting
page.
◆ MC-9130H/Atelemetryconnectionexample
SBM-2
ESC
ToCH3
Tofreeport
Todrivebattery
Throttle
ToS.BUS2
◆ Alarmsetting
Setsthecurrenton
whichthealarm
operates.
