SBS-01MLtelemetrydisplayscreen
Displays the status of the drone. Alarm setting is also possible.
TaptomovetotheGPS1Satellites
settingpage.
TaptomovetotheGPS1HDOP
settingpage.
TaptomovetotheGPS2Satellites
settingpage.
TaptomovetotheGPS2HDOP
settingpage.
TaptomovetotheAltitude
settingpage.
TaptomovetotheCurrent1
settingpage.
TaptomovetotheGround
Speedsettingpage.
TaptomovetotheVoltage2
settingpage.
TaptomovetotheAirspeed
settingpage.
TaptomovetotheCurrent2
settingpage.
TaptomovetotheVoltage1
settingpage.
*Beforeconnecting,makesurethatthetelemetryterminal
communicationspeedoftheflightcontrollerissetto57600bps.
(Defaultis57600bps.)
*Pixhawk
®
1andPixhawk
®
2andlaterhavedifferentconnectors,so
selectaconnectioncablethatmatchestheconnector.
*Thedatainthetableontherightisobtainedanddisplayedusingthe
MAVLinkprotocolfromtheflightcontroller.Devicesthatdo notuse
thesedataarenotsupported.
*OperationwithallPixhawk
®
flightcontrollersisnotguaranteed.
Item
MAVLink
Message Field
Numberof
GPS1
GPSRAWINT satellitesvisible
GPS1HDOP GPSRAWINT eph
Numberof
GPS2
GPS2RAW satellitesvisible
GPS2HDOP GPS2RAW eph
Altitude
GLOBAL
POSITIONINT
relativealt
Ground
speed
VFRHUD groundspeed
Airspeed VFRHUD airspeed
Voltage1
BATTERY
STATUS
voltages[0](id=0)
Current1
BATTERY
STATUS
currentbattery(id=0)
Voltage2
BATTERY
STATUS
voltages[0](id=1)
Current2
BATTERY
STATUS
currentbattery(id=1)
Displaymax/minvalue
Pressandholdtoreset.
Displaymax/minvalue
Pressandholdtoreset.
Displaymax/minvalue
Pressandholdtoreset.
●
Tap the [SBS-01ML] button in the Telemetry screen to call
the setup screen shown below.
