FUTABA T26SZ - Page 183

183
ڀ ŪŲŃƗƒŃŷŤťůŨŃŲũŃŦŲűŷŨűŷŶ
ŷƋƕƒƗƗƏƈŃƋƒƏƇ
This function sets the throttle cut position for
autorotation. The throttle position can also be set to
an idling position. Setting of these 2 positions can
be selected by switch. This allows use for switching
during training.
([DPSOHRIXVH
ŏ6LQFHWKURWWOHKROGKDVPRGHV&XW
and (Idle), using it in the Idling mode
during training and in the Cut mode when
stopping the engine at contest, etc. is
convenient.
Note: When throttle hold is set to ON in the normal
condition, throttle hold acts and the throttle servo
is deactivated. Always set throttle hold to ON in the
hold condition.
ŶƈƗƗƌƑƊŃƐƈƗƋƒƇ
ŏ2SHUDWLRQPRGHVHOHFWLRQ
Manual mode(Manual): The throttle hold function
is operated by switch operation only.
Auto mode(Auto): The throttle hold function
operation is linked to the throttle stick position.
Auto position setting: When the auto mode is
selected, the throttle position (auto position) can
be selected. Move the throttle stick to the position
you want to set and tap the screen. (Auto position
is displayed.)
ŏ+ROGSRVLWLRQDGMXVWPHQW
Throttle Hold (Cut) sets the throttle cut position.
Adjust it so that the carburetor is fully closed.
Throttle Hold (Idle): Make this adjustment to
maintain idling for training. Adjustments can be
made based on the throttle curve idle position.
ŏ7KHWKURWWOHVHUYRRSHUDWLQJVSHHGFDQEH
adjusted. (Speed)
ŏ7KURWWOHFXWRUWUDLQLQJIXQFWLRQFDQEHVZLWFKHGE\
hold function selector switch.
ŲƓƈƕƄƗƌƒƑŃƓƕƈƆƄƘƗƌƒƑƖ
WARNING
Whenstartingtheengine,confirmthat
theidleupconditionandthrottlehold
conditionareOFF.
ŏ6HOHFW>7KURWWOHKROG@DWWKHPRGHOPHQX
and call the setup screen shown below.
Currentposition
Holdposition
Enginecutsetting Engineidlesetting
Settotheengine
stopposition.
Settotheidling
position.
ŏ5HWXUQWR0RGHOPHQX
