●Mixingcurvesetting
*Foradescriptionofthecurvesettingmethod,
seethedescriptionatthebackofthismanual.
ŷƋƕƒƗƗƏƈŃƐƌƛƌƑƊ
This function corrects slowing of engine speed
caused by swash plate operation during aileron
or elevator operation. The method of applying
clockwise or counterclockwise torque when
pirouetting can also be corrected.
An acceleration function which temporarily
increases the throttle side correction rate relative to
rapid stick operation can also be set.
6HWWLQJH[DPSOH
ŏ$LOHURQWR7KURWWOHDSSOLHVDORDGWR
the engine and corrects slowing of the
engine speed when the aileron stick was
operated. Engine racing can be adjusted
independently at the right aileron and left
aileron by Rates A and B.
ŶƈƗƗƌƑƊŃƐƈƗƋƒƇ
ŏ:KHQXVLQJWKLVIXQFWLRQ7DS>,1+@21LV
displayed.)
ŏ:KHQ\RXZDQWWRVHWWKHVDPHFRQWHQWVDWRWKHU
conditions, select the group mode.
When you want to set the selected condition only,
select the single mode (initial setting).
ŏ7KHFRUUHFWLRQUDWHFDQEHVHWE\FXUYH
ŏ$VZLWFKFDQEHVHW
When [--] is set, the swash mixing function is
operated by merely selecting the condition.
When setting an [ON]/[OFF] switch, tap to the
[--] item and tap the screen to call the selection
screen and set the switch and its ON position.
When correction is necessary, tap to the mixing
item corresponding to the mixing that needs
correction and tap the screen to call the curve setup
screen, and then correct the slowing.
$FFHOHUDWLRQIXQFWLRQVHWWLQJ!
ŏ$FFHOHUDWLRQFDQEHVHWIRUERWKVHWWLQJV
(Left) and (Right)
ŏ$FFHOHUDWLRQUDWHVHWWLQJ5DWH
ŏ7KHUHWXUQWLPH'DPSLQJDIWHURSHUDWLRQ
can be set.
ŏ7KHRSHUDWLRQSRLQW$FWSRVLWLRQZKHQ
the correction rate is increased and
decreased can be set independently.
When an operation point is exceeded,
acceleration operation is performed.
ŏ6HOHFW>7KURWWOHPL[LQJ@DWWKHPRGHOPHQX
and call the setup screen shown below.
"Linear":Correction
appliedfortheentire
throttlerange.
"CTRM":Thecorrection
ratemaximumwhenthe
throttlestickiscentered.
ŏ5HWXUQWR0RGHOPHQX
