FUTABA T26SZ - Page 24

24
ڀ ŪŲŃƗƒŃŷŤťůŨŃŲũŃŦŲűŷŨűŷŶ
CAUTION
Besuretoturnoffthepowerto
thetransmitterbeforeinsertingor
removingthemicroSDcard.
AsthemicroSDcardisaprecision
device,donotuseexcessiveforcewhen
inserting.
-When a micro SD card is installed in the T26SZ
transmitter, a folder called "Futaba" is created.
Folders called "LOG" and "MODEL" are created
in this folder. The "MODEL" folder stores the
model data and the "LOG" folder stores the
telemetry log data.
-The telemetry log data recorded on the micro
SD card can be converted to CSV format by the
telemeter log converter released on our home
SDJH:KHQFRS\LQJRUPRYLQJDORJ¿OHDOZD\V
VHOHFWERWK)/,DQG)/'¿OH
ŷƕƄƌƑƈƕŃƆƒƑƑƈƆƗƒƕ
When you use the trainer function, connect the
optional trainer cable between the transmitters for
teacher and student.
*You can set the trainer function on the Trainer Function
screen in the System menu.
ŦƒƑƑƈƆƗƒƕ
ŶőťŸŶŃŃŋŶőŬŒũŌŃƆƒƑƑƈƆƗƒƕ
When using an S.BUS servo and telemetry sensor,
connect them both here.
ŨƄƕƓƋƒƑƈŃƍƄƆƎ
Connecting a stereo headphone to this jack, the
speech information of telemetry can be heard.
Use earphones with a 3.5mm plug.
(Using stereo earphones, the sound will only be
heard on one side.)
Earphone
jack
Opentherubbercover
Trainer
connector
S.BUS(S.I/F)
connector
