DLPH-2 mode setting
Setting of DLPH-2 is possible with T26SZ. DLPH-
2 setting can be performed on the T26SZ screen by
ZLULQJWKH'/3+DVVKRZQLQWKH¿JXUH
S.I/Fport
RX1port
5.
Tap [Read].
6.
The DLPH-2 settings will be displayed.
7.
&RQÀJXUHWKH'/3+
1.
Connect the power supply to the BAT.1 or BAT.2
port of DLPH-2.
3. Turn on the power switch of DLPH-2.
*Whensettingmodeissetto[Airplanegyromode],PWM
outputmodeisfixedto[1-16CH+DG1,DG2].
DualRXmode→SingleRXmode→Airplanegyromode→DualRXmode→．．．
1-16CH+DG1,DG2 → 17-24CH+DG1,DG2 → 1-16CH+DG1,DG2 →．．．
Modeselection
2.
Connect the RX1 port of the DLPH-2 and the S.I/F
port of the transmitter with a cable.
4. Tap [DLPH-2 setting] on the System menu.
9.
Remove DLPH-2 from the transmitter.
8.
Tap [Write].
→
DLPH-2 settings will be changed.
