Specifications
POWER REQUIREMENT
• Power Supply Adapter: 15 VDC/1.2 A
SOLID STATE RELAYS
• Part Number: G3VM-2F
• Application: Alarm Relay 1, 2
• Maximum Output Voltage: 250V (AC or DC)
• Maximum Output Current: 120 mA
Note: Internally limited and protected to 110V/100 mA
RESPONSE TIMES
• Conversion capture rate: every sample
• Peak capture rate: every sample
• Valley capture rate: every sample
• Conversion display update rate: 5 times per second
• Peak display update rate: 5 times per second
• Valley display update rate: 5 times per second
PASSWORDS
• Default Password: 0000000
• Alternative Password: Device’s Serial Number
PHYSICAL PROPERTIES
• Instrument Weight: 1.9 lbs. (862g) without mounting
bracket
• Dimensions: 3.8”(W) × 3.8”(L) × 6.5”(D)
BANDWIDTH
The digital output bandwidth has been specified as SPS/4.
The analog output bandwidth has been specified as SPS/4 for
sampling rates less than 1200 SPS and has been specified as
SPS/5 for sampling rates more than 1200 SPS if:
1. ASCII stream output is deactivated
2. IPM650 is not connected to computer
3. All relays are disabled
4. Display is in menu mode (Peak, Valley, Tracking, and data
display are main display mode)
