Futek IPM650 - Wiring Layout

7
Wiring Layout
STRAIN GAUGE INPUT
PIN SYMBOL DESCRIPTION
B1 G Ground/Shield
B2 TEDS TEDS Data
B3 –S –Signal
B4 +S +Signal
B5 –E –Excitation
B6 +E +Excitation
AMPLIFIED INPUT
PIN SYMBOL DESCRIPTION
A1 G Ground/Shield
A2 G Ground/Shield
A3 24V OUT 24VDC Output
A4 5V OUT 5VDC Output
A5 –V –V and –mA Amplified Input Connections
A6 +V +V and +mA Amplified Input Connections
A7 PLEAD n/a
A8 PLAG n/a
Note: Shield should only be connected on either sensor side or instrument side. If connected on instrument side use follow-
ing directions. Connect shield to pin A1 or pin A2 of Amplified Input if sensor is amplified. Connect shield to pin B1 of Strain
Gauge Input if sensor is strain gauge.
