Futek IPM650 - Important Information for IPM650; Performance; Product Introduction

6
IPM650
Channel
Enter
Reset Menu
Track/Hold
Tare/Gross
Unit
Power
Exit
Shunt
Display
Back
A1
B1 C1
D1
A2
B2 C2
D2
A3
B3 C3
D3
A4
B4 C4
D4
A5
B5
A6
B6
A7 A8
Amplified Input (page 7)
Strain Gauge Input
(page 7)
Relays
(page 8)
Analog Output
(page 8)
Power
Adapter
USB
Compatible with
USB 2.0 only
CONNECTION TIPS
The +/– Excitation and +/– Signal
connections are used with mV/V output
sensors with the
+/– Excitation used to supply
power to the sensor.
The 24V output supply can be used to
power amplified sensors, such as our
amplified Rotary Torque sensors (for
instance the TRS605).
View online wiring code here:
http://www.futek.com/wirecode.aspx
Connector Pin Configuration
