Rigging the fixture
DANGER OF FIRE!
When installing the device, make sure there is no highly inflammable
material (decoration articles, etc.) in between a distance of min. 0.5 m.
CAUTION!
Use 2 appropriate clamps to rig the fixture on the truss.
Follow the instructions mentioned at the bottom of the base.
Make sure that the device is fixed properly! Ensure that
the structure (truss) to which you are attaching the fixtures is secure.
The MH-640 can be placed directly on the stage floor
or rigged in any orientation on a truss without altering
its operation characteristics (see the drawing).
The fixture’s base enables to be mounted in two
ways. Use the clamps with screws M10 or M8 - check
the base bottom.
Install a safety-rope that can hold at least 10 times
the weight of the fixture. Never use the carrying
handles for secondary attachment.
Safety-rope
Clamp
