Futurecom DVR-LX - Configuration 5: Duplex Cross-Band Stacked

8M093X01 R1.0 33
Configuration 5: Duplex Cross-band Stacked
Refer to Standard Installation Cables section for mapping of cable diagram numbers to part numbers
Figure 29: Configuration 5 - Front View
Figure 30: Configuration 5 - Back View
8
3
1
8
To DVR
Antenna
To MSU
Antenna
