Status Lights
The relay outputs in the DVR-LX can be programmed to provide several status
indications Primary Light’, ‘VR On Light’, ‘LOC Mode Light’, or ‘SYS Mode Light’.
The DVR-LX then provides control input to an external switch which in turn toggles an
external light. The external switch and light are not included with the DVR-LX.
The light switch relay coil “+” must be wired to +12V DC and the “-“ to the corresponding
relay output on the DB15 connector of the DVR-LX auxiliary cable (500mA Max).
Refer to the programming instructions for Error! Reference source not found. to enable
this functionality.
AVRA
The Automated VR Activation (AVRA) option enables automated DVR-LX ON/OFF
control triggered by an external switch portable charger, door switch etc.
If this option is desired, the external switch (provided by others) needs to be wired to one
of the following:
Option 1: A dedicated VIP Input on the MSU Control Head or DEK
7
.
Option 2: ‘Switch 1 Input’ on the DB15 of the DVR-LX Auxiliary Cable.
Note: With an in-band configuration, the auxiliary cable is provided for use with AVRA.
For a cross-band configuration, the cable will need to be ordered separately- order
number: DDN9031.
Refer to the programming instructions for
Automated VR Activation (AVRA to enable this functionality.
7
For detailed instructions on VIP wiring, please refer to the MSU installation manuals available
from Motorola.
