FUXTEC FX-PS162 User Manual

Original User Manual FUXTEC FX-PS152 / FX-PS162
4
19. DISPOSAL NOTE ............................................................................................. 27
20. EC DECLARATION OF CONFORMITY ........................................................... 28
We are continually striving to improve our products. Therefore technical data and
illustrations may change!
1. Technical Data
Type FX-PS152 FX-PS162
Engine air-cooled; 2-stroke air-cooled; 2-stroke
Cubic capacity 51.7cm
3
62cm
3
Maximum output power (kW)
(conformity with ISO 8893)
2.2kW / 7,500min
-1
2.6kW / 7,500min
-1
The maximum speed of the engine 9,000 min
-1
9,000 min
-1
Idle speed of the device 3,000 min
-1
3,000 min
-1
The maximum speed of the spindle (motor
scythe)
7,100 min
-1
7,100 min
-1
The maximum speed of the spindle (lawn
trimmer)
6,600 min
-1
6,600 min
-1
L
PA
at the operator's position 99.5dB(A) (K=3dB) 101.0 dB(A) (K=3dB)
Measured L
WA
according to ISO 10884 107.7dB(A) (K=3dB) 106.9 dB(A) (K=3dB)
Guaranteed L
WA
113dB(A) 113dB(A)
Maximum vibration values at each handle
5.259m/s
2
k=1.5m/s
2
8.124m/s
2
k=1.5m/s
2
Maximum thread diameter Ф440mm (Φ2.5mm) Ф440mm (Φ2.5mm)
Diameter of the metal blade
305mmx1.6mm-2T /
255mmx1.6mm-3T/
255mmx1.6mm-4T/
255mmx1.6mm-8T
305mmx1.6mm-2T /
255mmx1.6mm-3T/
255mmx1.6mm-4T/
255mmx1.6mm-8T
Rotation direction of the cutting device
Counterclockwise (see the mark on
the plate)
Counterclockwise (see the
mark on the plate)
Number of the handle 2 pieces 2 pieces
Dry weight (without fuel, cutting assembly,
carrying strap)
8.5kg 8.67kg
Fuel tank capacity (L) 1.2 1.2
Fuel consumption (kg/h) (in accordance
with ISO 8893)
0.98 0.98
Specific fuel consumption (g/kWh) (in
accordance with ISO 8893)
630 630

FUXTEC FX-PS162 Specifications

General

Brand	FUXTEC
Model	FX-PS162
Category	Trimmer
Language	English
