7. Installation / Presettings
Read this manual thoroughly and carefully before installing and using your lawnmower.
IMPORTANT: The lawnmower is sold WITHOUT OIL OR FUEL. Your new lawnmower has been assembled and tested at the
factory.
REMOVE ANY CARDBOARD PARTS FROM THE LAWNMOWER
Remove the device from the box and check the entire packaging thoroughly for loose parts.
IMPORTANT: For assembly steps 1-3, depending on the model, your lawnmower will be delivered entirely pre-assembled
(assembly variant 1) or in two packages (assembly variant 2). We, therefore, ask you to consider two assembly variants in the
following. Assembly step 4 is the same for all variants.
Body version 1 (46s
models)
1. Remove the lawnmower from the packaging
2. Insert the lower spar (A) into the body and mount it laterally on the right and left with a screw.
3. Insert upper spar (B) and tighten with orange wing nut, then tighten screws + nuts on both sides.
B
A/1.
3.
