FUZRR ES3035 - Rang and Accuracy

- 5 -
Ω. DC voltage measurement range 0 ~ 1000V, AC voltage measurement range 0
~ 750V
。
III．Measuring Range and Accuracy
Test
Function
Output
Voltage
Measure Range Accuracy
Resoluti
on
Insulation
Resistance
100V(±10%)
0～10MΩ
±3%rdg±5dgt
0.01MΩ
10～100MΩ 0.1MΩ
100～1000MΩ 1MΩ
1G～10GΩ ±5%rdg±5dgt 0.01GΩ
250V(±10%)
0～10MΩ
±3%rdg±5dgt
0.01MΩ
10～100MΩ 0.1MΩ
100～1000MΩ 1MΩ
1G～10GΩ ±5%rdg±5dgt 0.01GΩ
500V(±10%)
0～10MΩ
±3%rdg±5dgt
0.01MΩ
10～100MΩ 0.1MΩ
100～1000MΩ 1MΩ
1G～10GΩ ±5%rdg±5dgt 0.01GΩ
1000V(±10%)
0～20MΩ
±3%rdg±5dgt
0.01MΩ
20～200MΩ 0.1MΩ
200～2000MΩ 1MΩ
2G～20GΩ ±5%rdg±5dgt 0.01GΩ
2500V(±10%)
0～2000MΩ ±3%rdg±5dgt 1MΩ
2000MΩ～20GΩ ±5%rdg±5dgt 0.01GΩ
20GΩ～200GΩ ±20%rdg±10dgt 0.1GΩ
5000V(±10%)
0～2000MΩ ±3%rdg±5dgt 1MΩ
2000MΩ～20GΩ ±5%rdg±5dgt 0.01GΩ
20GΩ～200GΩ ±20%rdg±10dgt 0.1GΩ
200GΩ～1000GΩ ±20%rdg±10dgt 1GΩ
Remark: Common electrical unit conversion
1 TΩ（Tera ohm）=1000GΩ=10
12
Ω
1 GΩ（Giga ohm）=1000MΩ=10
9
Ω
1 MΩ（Mega ohm）=1000KΩ=10
6
Ω
