FUZRR ES3035 - Technical Specifications

- 6 -
Test
Function
Measure Range Accuracy Resolution
DC Voltage
DC 0.0V～1000V ±1.5%rdg±3dgt 0.1V
AC Voltage
AC 0.0V～750V ±1.5%rdg±3dgt 0.1V
IV .Technical Specifications
Function
Insulation resistance test, voltage test
Base conditions
23°C±5°C，below 75%rh
Rated voltage(V)
100；250；500；1000；2500V；5000V
Test Voltage(V)
rated voltage×（1±10%）
Insulation Resistance
Range（GΩ）
0.01MΩ～1000GΩ
Insulation Resistance
Insulation
0.01MΩ
DC Voltage Range
0～1000V
DC Voltage resolution
0.1V
AC Voltage Range
0～750V
AC Voltage resolution
0.1V
Output short-circuit
Current
≥3mA(5KV)
Absorption Ratio and
Polarization Index
Measurement
Have
Power Supply
12V rechargeable battery
