Backlight
Controllable gray screen backlight, suitable for use in dim
places
Dispaly mode
4-bit large LCD display, gray screen backlight
LCD display size
108mm×65mm
Instrument size
L/W/H：277.2mm×227.5mm×153mm
USB interface
With USB interface, software monitoring, storage data can be
uploaded to the computer, save the print
Communication Line
USB communication line 1PC
Test Line
High voltage rob red 3meter, high voltage test line black
1.5meter, green 1.5meter
Data Storage
500 groups, "FULL" symbol indicates that storage is full
Data Review
Data review function: "MR" symbol display
Overflow Display
Exceed measurement range overflow function: “OL ” symbol
display
Alarm Function
Alarm when the measured value exceeds the alarm setting
value
Power Consumption
Standby: 30mA Max(backlight off)
Turn on backlight: 42mA Max
Measure：300mA Max(backlight off)
Instrument weight
2720g(including battery)
Battery voltage
When the battery voltage is low, low battery symbol
“ ”will display
Automatic shut-down
automatic shutdown after 15 minutes boot
Insulation Resistance
≥50MΩ(between Measuring line and housing)
Pressure Resistance
AC3kV/50Hz 1min
