3. Assembly Instructions
Ready the operation instructions carefully before use, then choose a flat position to assemble.
This treadmill also can use other way to account the HRC. When in fitness,user can wear the chest pulse belt and
the HRC will show in Pulse windows.
3.1. Pre-Assembly Check List
ITEM Description Qty ITEM Description Qty
A Treadmill frame 1 G Electronic meter 1
B Treadmill’s hand-stand pipe (left) 1 H Water cup 2
C Treadmill’s hand-stand pipe (right) 1 I Stand pipe decorative cover (left) 1
D Handrail pipe (left) 1 J Stand pipe decorative cover (right) 1
E Handrail pipe (right) 1 K Transporting pipe 2
F Water cup frame 1 L Electronic meter decorative cover 1
