7. Malfunction elimination
e
rror code
Possible reasons
Rectification measurements
Remark
No power for
computer
console
1 The power switch if off
turn on power switch
2 The power switch signal
light is off
check whether the power
socket has power with
ammeter
(110/220V) Check whether
the current supply is
(110/220V) or not
3. No DC 12V power
output from transducer
change transducer
4. control wire malfunction
change control wire
5. computer console
malfunction
change computer console
6. energy
-
saving small
board malfunction
change energy
-
saving small
board
7. WAKE key malfunction
change key board or wires
E01
low voltage from the
transducer power
change filter, choke,
transducer
Check whether the current
supply is (110/220V) or not
E02
abnormality for transducer
temperature senor
change transducer
E04
overcurrent output from
the transducer
add lubrication oil to bearing,
change transducer
E
06
overvoltage from the
transducer
change transducer brake
electrical resistance
E08
abnormality for the falling
of the transducer
change transducer
E09
overheat of the transducer
add lubrication oil to bearing,
change transducer
E10
abnormality
for overload of
transducer motor
change motor, transducer
E11
abnormality for overload of
transducer
add lubrication oil to bearing,
change transducer
E12
abnormality for overload of
transducer system
change transducer
E13
transducer motor off lin
e
change motor, transducer
E14
malfunction for transducer
brake
change transducer brake
electrical resistance
E33
malfunction for adapter
Flash
change adapter
E34
malfunction for transducer
Flash
change transducer
E35
transducer low voltage
warning display
change filter, choke,
transducer
Check whether the current
supply is (110/220V) or not
E37
transducer emergency
shutdown display
change transducer, control
wire, computer console
E41
transducer high heat
display
add lubrication oil to bear
ing,
change transducer
E77
abnormality for transducer
communication
change transducer, control
wire, computer console
E78
abnormality for key
buttons
change key and computer
