Zeroing the BX-1000 Gage Using the MIC TRAC (continued)
3. Locate the dimension for the type of groove
you are measuring in the MIC TRAC Setting
Dimensions table in this manual.
4. Turn the coarse adjust knob on the MT-3000 to
display a measurement that is close to the
desired setting dimension.
5. Secure the coarse adjust lock.
6. Turn the fine adjust knob until the CPU displays
the exact setting dimension.
7. Secure the fine adjust lock.
8. Loosen the lower block locking knobs and slide
the lower block to a position that allows the BX-
1000 gage to set on the top surfaces of the
setting blocks.
9. Place the BX-1000 gage on the setting blocks,
positioning the contact points between the
setting blocks.
