Gaggenau DF480100 - Etagere

en Features
24
2. Lift the basket forwards out of the
catches ⁠.
1
2
3. Lower the basket and pull out.
4. Slide the guide rails into the appli-
ance.
Installing the top basket
1. Pull the guide rails of the top bas-
ket out of the appliance ⁠.
2. Insert the top basket ⁠.
1
2
Observe the position of the detent
pins.
3. Lift the basket slightly and guide
the rear detent pins into the rear
locking hooks of the guide rails ⁠.
4. Lower the basket and press the
front detent pins into the notches
⁠.
a The basket clicks into position.
5. Slide the basket back into the ap-
pliance ⁠.
1
2
3
9.2 Etagere
Use the cutlery shelf and space un-
derneath for small cups and glasses
or for large items of cutlery, e.g.
cooking spoons or serving cutlery.
If you do not need the cutlery shelf,
you can fold it up.
