Gaggenau DF480100 - Basket Heights

Features en
29
2. Set the slider to ON or OFF.
3. Push in the top basket.
Cleaning Optional extra cleaning
area
Limescale and soiling from the dish-
washing water can block the nozzles.
Note:Always operate the appliance
with the Optional extra cleaning area
fitted.
1. Pull out the top basket.
2. Pull the tab on the Optional extra
cleaning area up and forwards
⁠.
3. Set the slider to ON.
4. Clean under running water.
5. Place the Optional extra cleaning
area in the top basket and lock in
position ⁠.
Check that the mounts are in the
correct position.
a The Optional extra cleaning area
audibly clicks into position ⁠.
6. Push in the top basket.
9.10 Basket heights
Set the baskets at the right height.
Appliance height 81.5cm with cutlery basket
Level Top basket Bottom basket
1 max. ø 22 cm
30 cm/31 cm →Page25
2 max. ø 24.5 cm 27.5 cm
