Gainscha GS-2406T PLUS Series User Manual

19
4.2 Regular Button Functions
This printer has two buttons for feed, pause or cancel errors. There are different functions
in different modes, as shown in the following table:
Button
Printer
status
Function
Description
Feed
button
Ready
Feed
When the printer is ready (Blue LED ON), press this
button once, and the label will advance to the front of
the next label
Feed
button
Wait for push
button to
print
Print next
When the button Demand function is activated, the
printer will stop after printing and wait for the user to
press this button before printing the next label.
Pause
button
Print mode
Pause
When the printer is printing continuously, pressing
the PAUSE button will pause printing. The power
indicator is blue flashing. Just press the button
again, and the print job returns to normal.
Pause
button
Error
occurred
Cancel error
When the error RED is on, press the PAUSE button
once, the printer will cancel the error and resume
printing function, and reprint the label layout when
the error occurs.

Gainscha GS-2406T PLUS Series Specifications

General

Model	GS-2406T PLUS Series
Print Method	Thermal Transfer / Direct Thermal
Resolution	203 DPI
Processor	32-bit RISC CPU
Print Speed	6 IPS
Max. Print Width	108 mm
Max. Print Length	2286 mm
Media Type	Continuous, Die-cut, Black Mark, Fan-fold
Media Width	118 mm
Media Thickness	0.06 mm - 0.25 mm
Media Roll Diameter	Max. 127 mm (5")
Label Length	10 mm - 2286 mm
Interfaces	USB, RS-232, Ethernet
Power Supply	AC 100-240V, 50/60Hz
Supported Barcode Types	Code 39, Code 128, UPC-A, UPC-E, EAN-8, EAN-13
Supported Fonts	Bitmap and TrueType fonts
