Gainscha GS-2406T PLUS Series User Manual

6
Power
External universal switching power supply
Input: AC 100-240V, 2.5A, 50-60Hz, Output: DC 24V, 2.5A, 60W
User Interface
• 1 power switch
• 2 buttons (Feed & Pause)
• 4 LEDs (Online, Error, Ribbon status, Communication)
Internal fonts
• 8 alpha-numeric bitmap fonts
• True type font engine (need download scalable font file)
1D Barcode
Code 11, Code 39, Code 93, Code 128 (subsets A, B, C), UPC-A, UPC-E, UCC-128, Codabar,
EAN/JAN-8, EAN/JAN-13, Interleaved 2 of 5, ITF14, MSI Pleassy, PostCode, Telepen
2D Barcode
QR Code, Micro QR Code, PDF417, Micro PDF417, MaxiCode, Aztec Code, Data Matrix
Rotation
Font and barcode support 0, 90, 180, 270 degree
Printer language
Compatible to TSPL, EPL, ZPL, ZPL II,DPL
Ribbon
300 M long, max. OD 67 mm, 1” core (ink coated outside)
Ribbon width
30 mm ~ 110 mm (1.18” ~ 4.3”)
Media type
Continuous, die-cut, black mark, fan-fold, notched (outside wound)
Media width
20~ 117 mm (0.7“ ~ 4.6“)
Media thickness
0.055 ~ 0.19 mm (2.16 ~ 7.4 mil)
Media core
diameter
25.4 mm (1”)
Label roll
capacity
127 mm (5“) OD
Label length
5 ~ 2,794 mm
(0.2“ ~ 110“)
5 ~ 1,016 mm (0.2“ ~
40“)
5 ~ 25,400 mm
(0.2“ ~ 1000“)
5 ~ 11,430 mm
(0.2“ ~ 450“)
Physical
dimension
273.8mm(D) x 217mm(W) x 190.3mm(H)
Enclosure
ABS plastic
Safety
regulation
FCC Class A, CE Class A, CCC, BIS, CB

Gainscha GS-2406T PLUS Series Specifications

General

Brand	Gainscha
Model	GS-2406T PLUS Series
Category	Label Maker
Language	English
