CLEAN AND CARE
CLEAN AND CARE
17
Light
Unplug or Disconnect power.
remove the screw on the glass window frame.
Screw off the bulbs from the lamp sockets carefully and replace
them .
DO NOT USE A BULB LARGER THAN 30 WATTS.
Close glass window frame and secure with screw removed in
step 2.
CAUTION: The light cover maybe very hot and please Do not
touch the lamp cover when light is on.
Light Cover
Lamp Cover
Screw
Light Bulb
Glass window
frame
Charcoal Filter Charcoal filter is used in a non-vented(recirculating)
installation. The filter should be changed every 6 to 12 months
depending on use.
Unplug or Disconnect power.
Using a Phillips screwdriver to remove the two screws from the
shell top and panel.
Open the door so you can lift the louver up to separate it from
the oven.
Change the charcoal filter.
Carefully push the louver back into place and replace the screw
remove in step 2.
To Next Page
