1. Parts ldentification
lmportant!
Assembly of a filter upstream
of the valve is mandatory.
Water Flow Direction
2. Setting up the
lrrigation Controller
2.
1
V
al
v
e an
d
Solenoi
d
Ass
e
mb
l
y
The mechanical opening lever is
black.The lever has 3 positions:
1. AUTO – mid position
2. CLOSE - rotating clockwise, in any position
3. OPEN - rotating counter clockwise
In normal working conditions, the lever
should
be in the middle, position
AUTO.
*If it is necessary to replace the solenoid, do
not disassemble the blue ring underneath
3
1
3
2
To Next Page
