3E2374 Sheep Auto Drafter User Manual
Page 26
front of
Control
Bridge
switched off
• E-Stop button
depressed
Drafter in stand
by and ready
for operation,
waiting for
communication
from the
remote or Entry
Gate button on
the Control
Bridge.
Double flash
• Sheep Auto
Drafter has
been
overridden by
the Entry Gate
button on the
Control Bridge,
waiting for
communication
from this
button only.
Release Mode
Red
(fault)
Wrapped
around
front of
Control
Bridge
• Sheep Auto
Drafter
switched off
• Sheep Auto
Drafter
operating
normally
Sheep Auto Drafter
in a fault state (see
Troubleshooting (p
42) for diagnosis)
Red
(E-Stop)
Beside E-
Stop button
on Control
Bridge
• Sheep Auto
Drafter
switched off
• Sheep Auto
Drafter
operating
normally
E-Stop button
depressed
Table 2. Function of LED lamps
Buttons
The Entry Gate button on the Control Bridge of the Sheep Auto Drafter has more
functionality than the same button on the remote control. If the Entry Gate
button on the Control Bridge is used to override the entry gate, then only the
Entry Gate button on the Control Bridge can resume normal operation.
The table below shows the abilities of the Entry Gate button when pressed on
the Control Bridge.
